12V Automotive Batteries MF/EFB
12VAutomotive Start-stop /EFB /DIN | |||||||||||
Gr.No | Type No. | Capacity | CCA(EN) | Dimension(mm) | Layout | Terminal | Hold-Down | ||||
L | W | H | TH | ||||||||
L0 | MF 54080 | 40 | 340 | 174 | 174 | 190 | 190 | 0 | A | B13 | MF |
L1 | MF 55010 50 390 207 174 190 190 0 A B13 MF | ||||||||||
LB1 | MF54430 | 44 | 350 | 207 | 174 | 175 | 175 | 0 | A | B13 | MF |
L2 | MF 56010 60 560 242 174 190 190 0 A B13 EFB | ||||||||||
MF 56030 | 60 | 640 | 242 | 174 | 190 | 190 | 0 | A | B13 | EFB | |
LB3 | MF 56510 65 650 277 174 175 175 0 A B13 EFB | ||||||||||
MF 56530 | 65 | 650 | 277 | 174 | 175 | 175 | 0 | A | B13 | EFB | |
L3 | MF 57010 70 650 277 174 190 190 0 A B13 EFB | ||||||||||
MF 57030 | 70 | 760 | 277 | 174 | 190 | 190 | 0 | A | B13 | EFB | |
LB4 | MF 57510 75 730 | 315 174 175 | 175 0 A B13 EFB | ||||||||
MF 57530 | 75 | 730 | 315 | 174 | 175 | 175 | 0 | A | B13 | EFB | |
L4 | MF 58010 80 730 315 174 190 190 0 A B13 EFB | ||||||||||
MF 58030 | 80 | 800 | 315 | 174 | 190 | 190 | 0 | A | B13 | EFB | |
L5 | MF 59510 95 900 354 174 190 190 0 A B13 EFB | ||||||||||
L6 | MF 61010 | 110 | 950 | 393 | 174 | 190 | 190 | 0 | A | B13 | EFB |
12VAutomotive Start-stop/EFB /JS | |||||||||||
Gr.No | Type No. | Capacity | CCA (SAE) | Dimension(mm) | Layout | Terminal | Hold-Down | ||||
L | W | H | TH | ||||||||
B19 | M42(55B19L) | 40 | 370 | 184 | 124 | 200 | 220 | 0 | A(B) | EFB | |
M42R(55B19R 40 370 184 124 200 | 220 1 A(B) EFB | ||||||||||
60B19L(M42) | 40 | 420 | 184 | 124 | 200 | 220 | 0 | A(B) | EFB | ||
B24 | N55(70B24L) 45 460 238 127 200 220 0 A(B) EFB | ||||||||||
80B24L(N55) | 50 | 500 | 238 | 127 | 200 | 220 | 0 | A(B) | EFB | ||
D23 | Q85(90D23L) 60 500 230 172 200 220 0 A EFB | ||||||||||
Q85R(90D23R) | 60 | 500 | 230 | 172 | 200 | 220 | 1 | A | EFB | ||
105D23L(Q90) | 65 | 610 230 172 | 200 220 0 | A | EFB | ||||||
D26 | S95(100D26L) | 65 | 630 | 257 | 172 | 200 | 220 | 0 | A | EFB | |
S100(125D26L) 70 650 257 172 200 220 0 A EFB | |||||||||||
D31 | T110(115D31L) | 80 | 800 | 302 | 172 | 200 | 220 | 0 | A | EFB | |
T115(145D31L) 90 820 302 172 200 220 0 A EFB | |||||||||||
12V Automotive Start-stop Batteries /AGM/VRLA/DIN
12VAutomotive Start-stop Batties/AGM/DN | |||||||||||
Gr.No | Type No. | Capacity | CCA(EN) | Dimension(mm) | Layout | Terminal | Hold-Down | ||||
L | W | H | TH | ||||||||
L1 | H4-50 | 50 | 570 | 207 | 175 | 190 | 190 | 0 | A | B13 | AGM |
L2 | H5-60 | 60 | 640 | 242 | 175 | 190 | 190 | 0 | A | B13 | AGM |
L3 | H6-70 | 70 | 720 | 277 | 175 | 190 | 190 | 0 | A | B13 | AGM |
L4 | H7-80 | 80 | 800 | 315 | 175 | 190 | 190 | 0 | A | B13 | AGM |
L5 | H8-92 | 95 | 850 | 354 | 175 | 190 | 190 | 0 | A | B13 | AGM |
L6 | H9-105 | 105 | 950 | 393 | 175 | 190 | 190 | 0 | A | B13 | AGM |
12V Automotive Batteries AGM/VRLA /SAE
12VAutomotive /AGM/SAE | |||||||||||
Gr.No | TypeNo | Capacity | CCA(EN) | Dimension(mm) | Layout | Terminal | Hold-Down | ||||
L | W | H | TH | ||||||||
M27 | M27-700 | 90 | 800 | 306 | 168 | 208 | 233 | 0/1 | Marine Twin | B1 | AGM |
G31 | G31-800 | 100 | 825 | 329 | 170 | 199 | 217 | 0/1 | Marine Twin | AGM | |
12VAutomotive Batteries /JIS/Hybrid (HEV)
12VAutomotive/JS/Hybrid(HEV) | |||||||||||
Gr.No | Type No. | Capacity | CCA(EN) | Dimension(mm) | Layout | Terminal | Hold-Down | ||||
L | W | H | TH | ||||||||
B20 | 550B20L | 35 | 272 | 184 | 127 | 200 | 220 | 0 | B | EFB | |
24 | S55824L | 48 | 325 | 238 | 127 | 200 | 220 | 0 | B | EFB | |
D23 | 555D23L | 65 | 670 | 230 | 172 | 200 | 220 | 0 | A | EFB | |
S55D23R | 65 | 670 | 230 | 172 | 200 | 220 | 1 | A | EFB | ||
D26 | S65D26L | 68 | 730 | 257 | 172 | 200 | 220 | 0 | A | EFB | |
S65D26R | 75 | 760 | 257 | 172 | 200 | 220 | 1 | A | EFB | ||
D31 | S75D31L | 80 | 800 | 302 | 172 | 200 | 220 | 0 | A | EFB | |
12VAutomotive Batteries /AGM/VRLA /Auxiliary/ICE
12VAutomothve /AGM/Auxillary | |||||||||||
Gr.No | Type No. | Capacity | CCA(EN) | Dimension(mm) | Layout | Terminal | Hold-Down | ||||
L | W | H | TH | ||||||||
12B | AUX-120 | 12 | 200 | 150 | 87 | 145 | 145 | 1 | M6-B | AGM | |
12D | AUX-12D | 12 | 200 | 150 | 87 | 140 | 140 | 1 | M6-D | AGM | |
12K | AUX-12K | 12 | 200 | 150 | 87 | 145 | 145 | 1 | M6-K | AGM | |
14L | AUX-14L | 14 | 200 | 150 | 87 | 145 | 145 | 1 | C(Minǐ) | AGM | |
10L | AUX-10L | 10 | 180 | 150 | 87 | 130 | 130 | 1 | M6-L | AGM | |
108 | AUX-10B | 10 | 180 | 150 | 87 | 130 | 130 | 1 | M6-B | AGM | |
10D | AUX-10D | 10 | 180 | 150 | 87 | 130 | 130 | 1 | M6-D | AGM | |
12VAutomotive Batteries /AGM/VRLA/EV
12VAutomothve /AGM/SAE | |||||||||||
Gr.No | Type No. | Capacity | CCA(EN) | Dimension(mm) | Layout | Terminal | Hold-Down | ||||
L | W | H | TH | ||||||||
B35 | B35 | 35 | 520 | 207 | 175 | 138 | 138 | 0 | A | B13 | MF |
B19 | 60B19RS | 35 | 184 | 124 | 201 | 221 | 1 | A | MF | ||
B24 | 85B24LS | 45 | 234 | 127 | 200 | 220 | 0 | A | MF | ||
133 | 6-QTF-33 | 33 | 198 | 132 | 171 | 171 | 1 | M5 | B1 | AGM | |
T30 | 6-QTF-30 | 33 | 198 | 131 | 170 | 170 | 1 | A | AGM | ||
B21 | 6-QTF-40 | 40 | 200 | 134 | 202 | 222 | 0/l | A | AGM | ||
12VAutomotive Batteries /Lithium battery
12VAutomothve /LIthlum battery | |||||||||||
Gr.No | Type No. | Capacity | CCA(EN) | Dimension(mm) | Layout | Terminal | Hold-Down | ||||
L | W | H | TH | ||||||||
P60 | PL60 | 60 | 1800 | 278 | 176 | 190 | 190 | 0 | A | B13 | |
E6H | E6H | 20 | 300 | 202 | 158 | 140 | 140 | 0 | B13 | ||
C8 | C8 | 136 | 48.6 | 49 | 49 | ||||||
710 | 710-1 | 330 ma | 58 | 39 | 17 | 8V | |||||
4V |
